Knightsbridge CU1100 10A Triple-Pole Fan Isolator – White Curved Edge

The Knightsbridge CU1100 is a white Curved Edge 10A triple-pole fan isolator. Its wide rocker is marked ON/OFF and FAN ISOLATOR, and screw-cap covers are included.

• Model: CU1100
• Switching: triple pole, fan isolator
• Rating: 10A, 230 V, 50 Hz
• Dimensions: 86 mm high × 86 mm wide; 23.4 mm overall depth
• Total projection / recessed depth: 11.4 mm / 12 mm
• Plate depth: 7 mm; the rocker adds 4.4 mm to the projection shown in the drawing
• Minimum mounting-box depth: 16 mm
• Construction: white thermoset resin
• Terminal capacity: 2 × 1.0 mm² or 2 × 1.5 mm²
• Protection: IP20, indoor use
• Manufacturer-listed standards: BS EN 60669-1 and BS EN 60669-2-4
• EAN: 5055832971863

Installation and fan-circuit suitability must be checked against the manufacturer instructions. Isolate the supply and verify that the circuit is dead before installation or maintenance.

Manufacturer dimensions

View the full-size CU1100 manufacturer drawing

Manufacturer documents

• CU1100 manufacturer datasheet (PDF)
• Manufacturer wiring-accessories instructions — DCJUN22 (PDF)
